01
回転のデュアルモーションと 革命、powerrulせん断混合
02
多様なのための多数のアジテーターブレード 材料加工アプリケーション
03
自動壁削り、材料残留物なし
04
ワンタッチリフトと下部、反変位ロック
05
正確な二重層バレルボディ 複数のプロセスのための温度制御
High Purity & Zero Metal Contamination
The BY-NMLS Full-Ceramic Sand Mill uses ceramic components for all material-contact parts, eliminating metal ion contamination. This is essential for sensitive applications like battery electrolytes, semiconductor slurries, and pharmaceuticals.
Superior Corrosion & Wear Resistance
With hardness exceeding alloy steel, the ceramic structure ensures long-term precision and reduced maintenance. It also resists corrosion from acids, alkalis, and organic solvents.
Low Friction & Effective Thermal Control
Smooth ceramic surfaces reduce friction and heat generation, protecting heat-sensitive materials from degradation, phase changes, or loss of activity.
Stable Operation & Process Versatility
The lightweight, rigid ceramic shaft enables low-vibration, high-speed operation for uniform grinding. Its design also supports both dry and wet processes with simple parameter adjustments.
Same series of products
BY-NMLS 1L
BY-NMLS 5L
BY-NMLS 2L
BY-NMLS 10L
BY-NMLS 1L
Equipment characteristics:
Dry Grinding
Wet Grinding
Pressurized Grinding
Cryogenic Grinding
Inert Gas Grinding
Dynamic Balancing Design
Low friction loss
Structural Compatibility
High purity and zero pollution
Excellent corrosion resistance and wear resistance
2.2
Main drive motor
(KW)
1
Effective cavity volume(L)
100-6000
Spindle speed
(r/min)
0.5
Feed capacityL/time
0.6-3.0
Grinding media size (mm)
40-60
Grinding media fill rate (%)
BY-NMLS 5L
Equipment characteristics:
Dry Grinding
Wet Grinding
Pressurized Grinding
Cryogenic Grinding
Inert Gas Grinding
Dynamic Balancing Design
Low friction loss
Structural Compatibility
High purity and zero pollution
Excellent corrosion resistance and wear resistance
5.5
Main drive motor
(KW)
5
Effective cavity volume(L)
100-4000
Spindle speed
(r/min)
2.5
Feed capacityL/time
0.6-3.0
Grinding media size (mm)
40-60
Grinding media fill rate (%)
BY-NMLS 2L
Equipment characteristics:
Dry Grinding
Wet Grinding
Pressurized Grinding
Cryogenic Grinding
Inert Gas Grinding
Dynamic Balancing Design
Low friction loss
Structural Compatibility
High purity and zero pollution
Excellent corrosion resistance and wear resistance
3
Main drive motor
(KW)
2
Effective cavity volume(L)
100-5000
Spindle speed
(r/min)
1
Feed capacityL/time
0.6-3.0
Grinding media size (mm)
40-60
Grinding media fill rate (%)
BY-NMLS 10L
Equipment characteristics:
Dry Grinding
Wet Grinding
Pressurized Grinding
Cryogenic Grinding
Inert Gas Grinding
Dynamic Balancing Design
Low friction loss
Structural Compatibility
High purity and zero pollution
Excellent corrosion resistance and wear resistance
7.5
Main drive motor
(KW)
10
E ective cavity
volume (L)
100-3000
Spindle speed
(r/min)
5
Feed capacityL/time
0.6-3.0
Grinding media size (mm)
40-60
Grinding media fill rate (%)
